TMS Europe LtdTMS Europe Ltd is a UKAS accredited calibration laboratory No.0461, as defined in our Schedule of Accreditation. As a UK manufacturer we're a member of Made in Britain.

TMS UBC2001 Block Calibrator

TMS UBC2001 Block Calibrator

TMS Stock Code:   UBC2001/240V/C

Price:   £ 980.00 (1,176.00 Including VAT at 20%)

Current Stock:   1
Displayed stock levels are updated daily, but may be affected by subsequent orders.
Current Availability:   1 - 2 days
  £220
Some models can be ordered online, or the whole range off-line.
[UKAS 0461 Logo]

Optional UKAS Calibration (at TMS standard points)

TMS Europe is a UKAS (ISO 17025) accredited calibration laboratory No. 0461. We offer this item with the option of a UKAS calibration certificate, with customer details, listing that unit's results at our stated standard points. For different calibration points, customer details, etc, please contact us with your requirements for a quote.
TMS standard points: Main well at 3 temperatures: 60, 150 and 300C at full and partial immersion, and 1 survey of both wells at 150C. Lead-time is typically 5 to 10 days (additional to unit's availability).

Description and Specifications
Description and Specifications

Dry Well Block Calibrator Temperature Reference

The UBC2001 is a very compact, highly portable, block calibrator designed for checking the accuracy of temperature sensors, thermometers and thermostats. It offers compact size, low cost, and the versatility of interchange Small Sleeves to cover a wide range of probe sizes.

The UBC2001 is constructed with an aluminium block with a main well (hole/pocket), which takes interchangeable sleeves in a wide range of popular probe sizes. It also features a test circuit and buzzer for accurately checking thermostat switching temperatures.

This Standard Kit version includes 4 different sleeve sizes to fit common probe sizes and a carry case. Additional sleeve sizes can also be ordered seperately.

UKAS (ISO 17025) calibration is optionally available.

Range: 35°C to 350°C
Accuracy: ±0.4 to 0.9°C (see datasheet for full details)
Supply Voltage: 230Vac
Sleeves/Inserts: 13mm UniSleeves sizes 3.2mm, 4.7mm, 6.5mm, 9.5mm included in this kit as standard.
Carry Case: Hard moulded black plastic case with handle and shaped foam lining included in this kit as standard.

Datasheets
Datasheets
